Description
1. CE FCC RoHS ERP PSE certificated
2. Anti-glare eye protection optics
3. Original patented design product
4. Designed with insulation to prevent electric shock.
5. Designed with air convection cooling, it operates at a lower and safer temperature
6. Equipped with high-efficiency IC constant driver
7. Energy-saving LED lighting for industrial projects
8. Waterproof IP65, 5 years warranty
9. 100W 150W power optional
10. Mainly used in factories, warehouses, garages, processing workshops, shopping malls, convention centers, sports venues. etc.
Share:
Product Introduction
Insulation and waterproof design
IP65 and IK10 rate, insulated safety
Insulated high temperature resistant housing,safe from electric shock
Polycarbonate PC insulation housing, melting point up to 280 degree
Toughness, strong oxidation resistance and corrosion resistance
Efficient heat dissipation design
Air convection cooling with temperature control protection
Aerodynamic air intakes are designed at the bottom and around the lamp body based on the principle of hot air flowing upwards. The incoming cold air circulates in the lamp body to cool down and is discharged through the heat dissipation vents designed on the outer and top.A large amount of hot air to achieve the purpose of high-performance heat dissipation
High density aluminum heat sink
Built-in aviation grade high purity aluminum radiator
Using large area 6063 high-purity aviation aluminum thermal conductivity up to 3.0 or moreHeat dissipation speed is fast and lightweight
The use of polycarbonate PC insulation housing and high purity aluminum, its material characteristics of high density and low purity to achieve light weight
OPTICAL INSPECTION REPORT
If you need ies report, please consult our business
We can provide professional lighting solutions and lighting simulation effect solutions
APPLICATION SCENARIO DISPLAY
Datasheet
Guangdong LUFUL Lighting Technology Co., Ltd.
| UFO Anti-glare High Bay Light | |||||||||||||||
| Spec Sheet Revision Date: 2024-12-01 | |||||||||||||||
| Model: LF-UFO-F-100-150W | |||||||||||||||
| Electricity Parameter | |||||||||||||||
| ·Rated Power: | 100W 150W | ||||||||||||||
| ·Working Power: | 100W 150W（±5%） | ||||||||||||||
| ·Input Voltage: | AC100-277V | ||||||||||||||
| ·Freqency Range: | 50/60Hz | ||||||||||||||
| ·Power Factor: | ＞0.9 | ||||||||||||||
| ·Power Efficiency: | 88﹪ | ||||||||||||||
| Optical Parameter | |||||||||||||||
| ·Light source configuration | Sanan | ||||||||||||||
| ·Color Temperature: | 3000K 4000K 6500K | ||||||||||||||
| ·Led Initial Flux: | 16000-24000lm | ||||||||||||||
| ·Luminous Efficiency: | 160LM/W（±5%） | ||||||||||||||
| ·Light attenuation standard | ≥25000 | ||||||||||||||
| ·Power configuration: | Non-isolated IC Driver | ||||||||||||||
| ·Color Rendering Index: | Ra＞80 | ||||||||||||||
| ·Luminous Anlge: | 120° | ||||||||||||||
| Lamp Specification | |||||||||||||||
| ·Lamp Material: | PC with aluminum heat sink | ||||||||||||||
| ·Lampshade Material: | Lens Cover | ||||||||||||||
| ·Lamp Colour: | Black | ||||||||||||||
| ·Installation: | Chain Hanging / Mounting Bracket / Reflector / Screw Converter | ||||||||||||||
| ·Lamp Weight : | 2.85KG | ||||||||||||||
| ·Overall Dimension : | φ333*191mm | ||||||||||||||
| ·IP Grade : | IP65 | ||||||||||||||
| ·Working Temperature : | —20℃—60℃ | ||||||||||||||
| ·Working Life-span : | 35000H | ||||||||||||||
